Banner Engineering SSA-EB Flush-Mount Emergency Stop Button
Banner Engineering SSA-EB Flush-Mount Emergency Stop Button
Description
The Banner Engineering SSA-EB Flush-Mount is an emergency stop button built to install directly into a panel cutout for a compact, integrated profile, rather than sitting on Banner’s separate 30 mm mounting base. Like the standard SSA-EB, its patented design flashes red when actuated and shows green, yellow or no illumination to indicate armed status, and select models add In-Series Diagnostics (ISD) so multiple buttons on one line report individual status to an HMI. Safe Break Action opens the normally closed safety contacts if the contact block is ever separated from the actuator.
- Function: flush, panel-mount emergency stop pushbutton
- Mounting: flush panel-cutout mount (no separate mounting collar)
- Diagnostics: In-Series Diagnostics (ISD) on supported models
- Illumination: two-color (yellow or green and red), single-color red, or non-illuminated
- Contacts: latching design, Safe Break Action on NC contacts
- Standards: ISO 13850, IEC 60947-5-1, ANSI B11.19, ANSI/NFPA 79, IEC/EN 60204-1
- Housing rating: IP65
Specifications
| Distributed By | Seltrol, Sensors Incorporated |
|---|---|
| Brand | Banner Engineering |
| Series | SSA-EB |
| Selling Unit | Each |
