One skid, one power connection, one air outlet – the whole compressed air system

Specifying a compressed air system usually means sourcing a compressor, a receiver, a dryer, filtration and drains, then paying someone to tie it all together. The Gardner Denver L05TD AirStation arrives with all of it factory-mounted and piped: compressor, ASME-rated receiver, refrigerated dryer, filtration and automatic drains on a single footprint.

At a glance:
– 7 HP delivering 30.4 CFM at 190 psig
– Integrated air dryer built into the package

Why customers choose it:
– Complete all-in-one system: compressor, ASME receiver, refrigerated dryer, filtration and drains
– Single electrical connection and single air outlet simplify installation
– Tri-voltage compatibility (208/230/460V) with wye-delta starter
– Stainless steel interconnecting piping resists corrosion downstream of the aftercooler
– GD Governor controller manages load/unload and flags service before it becomes downtime
– TEFC motor and enclosed cabinet suitable for the production floor
– Electric tank and dryer drains standard

Built for:
– First compressed air system for a growing plant
– Replacing an aging compressor, dryer and tank in one move
– Facilities without a dedicated compressor room
– Shops that want a single point of accountability rather than five vendors

Not sure this is the right size for your plant? Tavoron’s compressed air team will size it against your actual demand, handle installation and startup, and support it afterward. Contact us for a quote.

Distributed By	JHFOSTER
Brand	Gardner Denver
Series	L-Series AirStation
Selling Unit	Each
Compressor Type	Rotary Screw
Variable Speed Drive	No
Motor Horsepower	7.00
Airflow Rate (CFM)	30.40
Maximum Operating Pressure (psi)	190
Integrated Air Dryer	Yes

Technical Data Sheet
