Robotiq FT 300-S Force Torque Sensor
Robotiq FT 300-S Force Torque Sensor
Description
The Robotiq FT 300-S is a six-axis force torque sensor that mounts between a collaborative robot wrist and its end effector. It measures ±300 N and ±30 Nm with 0.1 N signal noise on the force axes, streaming over RS-485 at 100 Hz. Couplings are available for Universal Robots CB and e-Series, Techman and Omron TM arms.
- Force measuring range: ±300 N on Fx, Fy and Fz
- Torque measuring range: ±30 Nm on Mx, My and Mz
- Signal noise: 0.1 N force; 0.005 Nm on Mx and My; 0.003 Nm on Mz
- Overload capacity: 500 % of measuring range
- Data output rate: 100 Hz; communication RS-485
- Supply voltage: 5 to 24 V DC ±10 %, 2 W maximum
- Dimensions: 89 mm robot-side diameter, 75 mm tool-side diameter, 41.5 mm thick; weight 442 g
- Protection rating: IP65; operating temperature 5 to 40 °C
Specifications
| Brand | Robotiq |
|---|---|
| Series | FT 300 |
| Manufacturer Part Number | FT 300-S |
| Selling Unit | Each |
