TOYO Robotics ETH13 Series Actuator
TOYO Robotics ETH13 Series Actuator
Description
The TOYO Robotics ETH13 is a standard ball screw driven linear actuator from the ETH Series, built with a class C7 rolled ball screw for high accuracy and repeatability and supported by precision-grade recirculating linear guides for smooth, accurate motion. Its durable aluminum construction provides a strong, stable mounting surface, with both tapped and through-hole mounting options. Based on a 10,000 km travel life rating, the ETH13 offers a repeatability of ±0.01 mm, a maximum horizontal payload of 70 kg, a maximum vertical payload of 17 kg, a maximum speed of 1000 mm/sec, and available stroke lengths of 100-1050 mm.
- Class C7 rolled ball screw for high accuracy and repeatability
- Precision recirculating linear guides for smooth, accurate motion
- Durable aluminum construction for a strong, stable mounting surface
- Tapped and through-hole mounting options
- Motor adaptor plate and coupling included
- Optional limit switches for precise motion control
- Optional flush cover plate helps prevent pinch points
- Configurable for Cartesian multi-axis systems; stroke length and additional carriages can be customized
Specifications
| Distributed By | Accu Tech USA |
|---|---|
| Brand | TOYO Robotics |
| Series | ETH13 |
| Selling Unit | Each |
| Country of Origin | Taiwan |
| Color | Gray |
