Contrinex DW-AS-503-M12 Inductive Proximity Sensor
Contrinex DW-AS-503-M12 Inductive Proximity Sensor
Description
The Contrinex DW-AS-503-M12 is a 12 mm tubular inductive proximity sensor from the standard 500 series with a semi-flush sensing face. It detects metal targets and switches a PNP normally-open output over an IO-Link interface for general-purpose part and position detection. The chrome-plated brass housing is rated IP67 for standard industrial duty.
- Sensing mode: inductive, semi-flush mounting
- Sensing distance: 6 mm
- Supply voltage: 10 to 30 V DC
- Switching frequency: 800 Hz
- Output: PNP, normally open (NO)
- Communication: IO-Link
- Connection: 4-pin M12 quick-disconnect
- Enclosure rating: IP67
Specifications
| Distributed By | Seltrol, Sensors Incorporated |
|---|---|
| Brand | Contrinex |
| Manufacturer Part Number | DW-AS-503-M12 |
| Selling Unit | Each |
