Contrinex DW-HD-603-M50-300 Inductive Proximity Sensor
Contrinex DW-HD-603-M50-300 Inductive Proximity Sensor
Description
The Contrinex DW-HD-603-M50-300 is a 50 mm high-temperature inductive proximity sensor built for operation near hot process equipment. It detects metal targets and switches a PNP normally-open output through a PTFE and PUR cable, and its quasi-embeddable sensing face suits oven and dryer-adjacent position sensing. The stainless steel V2A housing carries an IP67 rating and is rated up to 180 degrees C.
- Sensing mode: inductive, quasi-embeddable mounting
- Sensing distance: 20 mm
- Supply voltage: 10 to 30 V DC
- Switching frequency: 150 Hz
- Output: PNP, normally open (NO)
- Connection: PTFE and PUR cable, 3-wire
- Housing: 50 mm stainless steel threaded barrel, IP67
- Temperature rating: up to 180 °C
Specifications
| Distributed By | Seltrol, Sensors Incorporated |
|---|---|
| Brand | Contrinex |
| Manufacturer Part Number | DW-HD-603-M50-300 |
| Selling Unit | Each |
