Contrinex DW-AS-713-M12 Inductive Proximity Sensor
Contrinex DW-AS-713-M12 Inductive Proximity Sensor
Description
The Contrinex DW-AS-713-M12 is a full-metal, non-flush inductive proximity sensor in a 12 mm threaded stainless steel barrel from the “Full Inox” 700 series. It detects ferrous and non-ferrous metal targets and switches a PNP normally-open output over an IO-Link interface, and its extended non-flush range suits detection in harsh, wash-down or weld-adjacent environments. The stainless steel housing carries an IP68/IP69K rating.
- Sensing mode: inductive, non-flush mounting
- Sensing distance: 10 mm
- Supply voltage: 10 to 30 V DC
- Switching frequency: 400 Hz
- Output: PNP, normally open (NO)
- Communication: IO-Link
- Connection: 4-pin M12 quick-disconnect
- Housing: 12 mm stainless steel threaded barrel, IP68 and IP69K, -25 to 85 °C
Specifications
| Distributed By | Seltrol, Sensors Incorporated |
|---|---|
| Brand | Contrinex |
| Manufacturer Part Number | DW-AS-713-M12 |
| Selling Unit | Each |
